Horn 2 C2 (D5906B)

Harness-Family: Front_End_Module

Color: BLACK

Gender: FEMALE

Part Number: 7123-5014-30

Part Description: INSULATOR

Connector No: D5906B

Option: ~~

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 2 C2 Component Location

GCWD1205899

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

B1

Z920

BK

18

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
