Antenna-Radio C2 (D5901B)

Harness-Family: DeckLid

Color: BLACK

Gender: MALE

Part Number: 7282-2010-30

Part Description: 090-2 1P CONNECTOR SUB-ASSEMBLY

Connector No: D5901B

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Antenna-Radio C2 Connector End View

GCWD1090664

Courtesy of CHRYSLER

Fig 2: Antenna-Radio C2 Component Location

GCWD1206006

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X62

GY/OR

18

AMPLIFIED ANTENNA FEED

N/A

⁽¹⁾	Pins not listed are not used for this connector
