Airbag-Side Thorax-Left (D6679)

Harness-Family: Seat_Bag_Driver

Color: BROWN

Gender: FEMALE

Part Number: 54550267

Part Description: CONNECTOR ASSEMBLY (ABX-3 AIRBAG)

Connector No: D6679

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Airbag-Side Thorax-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Airbag-Side Thorax-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

VT/LB

LEFT SEAT THORAX SQUIB 1 LINE 2

N/A

GY/LG

LEFT SEAT THORAX SQUIB 1 LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
