Actuator-Blend Door-Left (D53)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 0-1419158-1

Part Description: 1X6P GET SOCKET HOUSING ASSEMBLY

Connector No: D53

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Actuator-Blend Door-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Actuator-Blend Door-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C34

DB/LB

COMMON DOOR DRIVER

N/A

C61

DB/LG

BLEND DOOR DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
