Transponder-Tire Pressure-Right Rear (D8123A)

Harness-Family: Unibody

Color: BLACK

Gender: FEMALE

Part Number: 1-638514-4

Part Description: CONNECTOR ASSEMBLY

Connector No: D8123A

Option: ~~

Repair Kit Part Number: 68032364AA

Cavity Count: 6

Fig 1: Transponder-Tire Pressure-Right Rear Connector End View
GCWD1024384Courtesy of CHRYSLER
Fig 2: Transponder-Tire Pressure-Right Rear Component Location
GCWD1206037Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
2 D508 WT/GY 22 LIN TIRE PRESSURE MONITOR LAN N/A
3 Z917 BK 22 GROUND N/A
6 Z917 BK 20 GROUND N/A
(1) Pins not listed are not used for this connector
