Starter-B(+) (3.6L) (D6637B)

Harness-Family: Engine

Color: BROWN

Gender: FEMALE

Part Number: 13801362

Part Description: Not Available

Connector No: D6637B

Option: 3.6L

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Starter-B(+) Connector End View (3.6L)

GCWD1014227

Courtesy of CHRYSLER

Fig 2: Starter-B(+) Component Location (3.6L)

GCWD1205999

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A8

RD

04

B(+)

N/A

1

A802

DG

10

B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
