Solenoid-Camshaft 1/2 Position (D63)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 7223-1324-30

Part Description: Not Available

Connector No: D63

Option: ~~

Repair Kit Part Number: 68030134AA

Cavity Count:

Fig 1: Solenoid-Camshaft 1/2 Position Connector End View

Courtesy of CHRYSLER

Fig 2: Solenoid-Camshaft 1/2 Position Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z901

GROUND

N/A

K276

DB/WT

VVT EXHAUST CONTROL

N/A

K276

DB/WT

VVT EXHAUST CONTROL

N/A

Z901

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
