Seat Belt-Retractor TENSIONER-Driver (D6673)

Harness-Family: Seat_Bag_Driver

Color: BLACK

Gender: FEMALE

Part Number: 02SQS2-BGI-0A-RK

Part Description: SQS-II CONNECTOR

Connector No: D6673

Option: ~~

Repair Kit Part Number: 68001949AA

Cavity Count: 2

Fig 1: Seat Belt-Retractor Tensioner-Driver Connector End View

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner-Driver Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R53

LG/YL

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

R503

LG/YL

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

R55

LG/DG

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

R505

LG/DG

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
