Pump-Secondary Air C1 (D6693A)

Harness-Family: HDLP_Dash

Color: GRAY

Gender: MALE

Part Number: 7282-5543-10

Part Description: Not Available

Connector No: D6693A

Option: ~~

Repair Kit Part Number: 68020943AA

Cavity Count:

Fig 1: Pump-Secondary Air C1 Connector End View

GCWD1091945

Courtesy of CHRYSLER

Fig 2: Pump-Secondary Air C1 Component Location

GCWD1205950

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z931

BK

10

GROUND

N/A

2

A961

LB/WT

12

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
