Horn 2 C1 (D5906A)

Harness-Family: Front_End_Module

Color: BLACK

Gender: FEMALE

Part Number: 7123-5014-30

Part Description: INSULATOR

Connector No: D5906A

Option: ~~

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 2 C1 Component Location

GCWD1205900

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

A1

X22

GY/LB

18

FUSED HORN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
