Airbag-Passenger Squib 2 (D6665B)

Harness-Family: IP

Color: YELLOW

Gender: FEMALE

Part Number: PPI0001462

Part Description: SRS CONNECTOR AK2 FERRITE

Connector No: D6665B

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Airbag-Passenger Squib 2 Connector End View

Courtesy of CHRYSLER

Fig 2: Airbag-Passenger Squib 2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R62

LB/VT

PASSENGER SQUIB 2 LINE 2

N/A

R64

LB/WT

PASSENGER SQUIB 2 LINE 1

N/A

R62

LB/VT

PASSENGER SQUIB 2 LINE 2

N/A

R64

LB/WT

PASSENGER SQUIB 2 LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
