Mid Panel Weatherstrip

Fig 1: Right And Left Center Rail Trim & Push Pins

Courtesy of CHRYSLER GROUP, LLC

Position top to the vertical position. Refer to DECKLID/HATCH/LIFTGATE/TAILGATE .
Using a trim stick or equivalent, gently remove both push pins (2) in the bottom of the right and left center rail trim (1).
Gently pry off both left and right center rail trim.

Fig 2: Drain Tubes
Courtesy of CHRYSLER GROUP, LLC
Disengage front and rear drain tubes (1) from each side.

Fig 3: Mid Panel Weatherstrip Fasteners
Courtesy of CHRYSLER GROUP, LLC
Remove eight fasteners (1), two per corner, from the mid panel weatherstrip.

Fig 4: Seal Retainer & Weatherstrip
Courtesy of CHRYSLER GROUP, LLC
Carefully pull side rail portion of the weatherstrip (2) away from the seal retainer (2).
Carefully pull cross-car portion of the seal away from the panel.
Lift seal around mid panel and remove from vehicle.
