Installation

INSTALLATION





1. Position the vacuum pump assembly (1), ensuring that the two ground leads are in place while installing bracket mounting bolts (2). Tighten bolts to 55 Nm (41 ft. lbs.).
2. Attach the harness connector to the bracket and connect the electrical connector (3).





3. Connect the quick-connect vacuum hose (1) to the vacuum pump (2) and seat the locking tab.
4. Install the engine appearance cover.
