Weatherstrip, Door: Removal: Removal

WARNING: This page is about a different car, the 2011 RAM Pickup and 2011 RAM Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Inner Belt Molding
GC0088951Courtesy of CHRYSLER LLC
  1. Open the appropriate door.
  2. If removing the rear door seal, using a trim stick or equivalent, remove the rear trim from the rear door.
  3. Carefully remove the door seal (6) from the door retainers.
  4. Remove the seal from the door.
