SENSOR, Air Temperature, Intake: Removal: 4.7L
WARNING: This page is about a different car, the 2011 RAM Pickup and 2011 RAM Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of CHRYSLER LLC
The intake manifold air temperature (IAT) sensor (1) is located near the throttle body.
- Disconnect electrical connector (2) from IAT sensor.
Courtesy of CHRYSLER LLC
| 1 - IAT SENSOR |
| 2 - SENSOR O-RING |
| 3 - RELEASE TAB |
- Clean dirt from sensor base.
- Gently lift on small plastic release tab (3) and rotate sensor about 1/4 turn counterclockwise for removal.
- Check condition of sensor o-ring (2).
