Switch, Brake Fluid Level: Installation: Installation

WARNING: This page is about a different car, the 2014 RAM 1500. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Connecting Wiring Harness Connector To Brake Fluid Level Switch
GC0158122Courtesy of CHRYSLER GROUP, LLC
  1. Insert brake fluid level switch into side of reservoir. Be sure to push switch in until retaining tab locks into place in reservoir.
  2. Connect wiring harness connector (2) to brake fluid level switch mounted in brake fluid reservoir.
