Seat Back: Removal: Removal: Sedan

WARNING: This page is about a different car, the 2013 Dodge Avenger and 2013 Chrysler 200. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Rear Seat Back & Fasteners
GC0123055Courtesy of CHRYSLER GROUP, LLC
  1. Pull upward at forward edge of the cushion (3) at each retainer loop of the rear seat cushion to disengage the retainer loops from cups in the floor (2).
  2. Guide the seat belts through the loops.
  3. Remove the rear seat cushion from vehicle.
  4. Remove the rear seat buckles and belt anchors. Refer to BUCKLE, SEAT BELT, REMOVAL .
  5. Remove the outer seat back bracket nuts (1).
    Fig 2: Rear Seat Cushion & Retainers
    GC0123056Courtesy of CHRYSLER GROUP, LLC
  6. Release folding rear seat back latches and fold the seats down completely.
  7. Remove the seat back fasteners securing the seat back to the floor.
  8. Remove seat back (2) from the vehicle.
