Rocker Housing
WARNING: This page is about a different car, the 2013 RAM 3500 HD and 2013 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.
- Clean all the gasket sealing surfaces. Refer to ENGINE GASKET SURFACE PREPARATION .
- Install and center rocker housing gasket (2) in groove. If gasket bead that is tilted to the side will cause an oil leak.CAUTION:
When installing rocker housing onto cylinder head, do not slide housing from side to side, The gasket could fall out or be damaged.
- Install the rocker housing (1) and tighten bolts finger tight. Working from center out, tighten bolts to 24 N.m (18 ft. lbs.).
- Install the cylinder head cover. Refer to COVER(S), CYLINDER HEAD, INSTALLATION, 6.7L .
