Special Tools

WARNING: This page is about a different car, the 2017 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of CHRYSLER GROUP, LLC	1130 - Splitter, Bearing/Gear (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9202, 9202A-CAN, 9202CC, 9299.)
Courtesy of CHRYSLER GROUP, LLC	6741 - Screw (Originally Shipped In Kit Number(s) 6730, 6731, 9516A-CAN, 9540, 9541.)
Courtesy of CHRYSLER GROUP, LLC	8153 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8104.)
Courtesy of CHRYSLER GROUP, LLC	8289 - Set, Arbor Disc (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8883A - Wrench, Differential Adjusting (Originally Shipped In Kit Number(s) 8887.)
Courtesy of CHRYSLER GROUP, LLC	8897 - Gauge, Pinion Height (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8954 - Hub Nut Socket (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8961 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8963 - Installer, Hub Seal (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8964 - Plug, Differential Bearing (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8965 - Installer, Differential Bearing (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8968 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8977 - Pinion Driver (Originally Shipped In Kit Number(s) 8887, 8887CC.)
Courtesy of CHRYSLER GROUP, LLC	8979 - Wrench, Pinion Flange (Originally Shipped In Kit Number(s) 8999.)
Courtesy of CHRYSLER GROUP, LLC	8992 - Remover, Pinion Flange (Originally Shipped In Kit Number(s) 8999, 8999CC, 9299, 9299CC, 9299CC, 9300A-CAN.)
Courtesy of CHRYSLER GROUP, LLC	938 - Bridge (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9202, 9202A-CAN, 9202CC, 9299.)
Courtesy of CHRYSLER GROUP, LLC	C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.)
Courtesy of CHRYSLER GROUP, LLC	C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.)
Courtesy of CHRYSLER GROUP, LLC	D-115-2A - Block, Scooter (Originally Shipped In Kit Number(s) 9329-SUP, 9515-SUP, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP, 9694, 9926.)
Courtesy of CHRYSLER GROUP, LLC	D-115-3 - Arbor (Originally Shipped In Kit Number(s) 8667, 9516A-CAN.)
Courtesy of CHRYSLER GROUP, LLC	L-4438 - Dial Indicator Post
Courtesy of CHRYSLER GROUP, LLC	2012800030 - Guide, Hub (Originally Shipped In Kit Number(s) 2012800030.)
Courtesy of CHRYSLER GROUP, LLC	2018800030 - Cone Nut, Pinion
Courtesy of CHRYSLER GROUP, LLC	2018900030 - Installer, Front Pinion Seal
Courtesy of CHRYSLER GROUP, LLC	2019000030 - Installer, Front Pinion Bearing Race
Courtesy of CHRYSLER GROUP, LLC	2019100030 - Installer, Rear Pinion Bearing Race
Courtesy of CHRYSLER GROUP, LLC	2019200030 - Installer, Rear Pinion Bearing
Courtesy of CHRYSLER GROUP, LLC	2019300030 - Installer, Bearing and Pinion Assembly
Courtesy of CHRYSLER GROUP, LLC	2019400030 - Height Block, Rear Pinion Bearing
