Body, Air Cleaner: Removal

WARNING: This page is about a different car, the 2017 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.
GC0161568Courtesy of CHRYSLER GROUP, LLC
  1. Separate the intake tube (1) from air cleaner body.
    GC0161548Courtesy of CHRYSLER GROUP, LLC
  2. Disconnect the Mass Air Flow sensor (MAF) (1) electrical connector (2).
    GC0161591Courtesy of CHRYSLER GROUP, LLC
  3. Pull the air cleaner body (1) straight upward to disengage it from the grommets (2).
