Special Tools
WARNING: This page is about a different car, the 2016 RAM 3500 HD and 2016 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.
| 1130 - Splitter, Bearing/Gear (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9202, 9202A-CAN, 9202CC, 9299.) |
|
| 6739 - Block, Height (Originally Shipped In Kit Number(s) 6730, 9516A-CAN, 9540, 9541.) |
|
| 6740 - Cone (Originally Shipped In Kit Number(s) 6730, 6731, 9516A-CAN, 9540, 9541.) |
|
| 6741 - Screw (Originally Shipped In Kit Number(s) 6730, 6731, 9516A-CAN, 9540, 9541.) |
|
| 8153 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8104.) |
|
| 8289 - Set, Arbor Disc (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8883A - Wrench, Differential Adjusting (Originally Shipped In Kit Number(s) 8887.) |
|
| 8896 - Installer, Seal (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8897 - Gauge, Pinion Height (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8960 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8961 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8963 - Installer, Hub Seal (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8964 - Plug, Differential Bearing (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8965 - Installer, Differential Bearing (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8968 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8977 - Pinion Driver (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8979 - Wrench, Pinion Flange (Originally Shipped In Kit Number(s) 8999.) |
|
| 8981 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8887, 8887CC.) |
|
| 8992 - Remover, Pinion Flange (Originally Shipped In Kit Number(s) 8999, 8999CC, 9299, 9299CC, 9299CC, 9300A-CAN.) |
|
| 938 - Bridge (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9202, 9202A-CAN, 9202CC, 9299.) |
|
| 10062A - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 10045.) |
|
| C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) |
|
| C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) |
|
| D-115-2A - Block, Scooter (Originally Shipped In Kit Number(s) 9329-SUP, 9515-SUP, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP, 9694, 9926.) |
|
| D-115-3 - Arbor (Originally Shipped In Kit Number(s) 8667, 9516A-CAN.) |
|
| L-4438 - Dial Indicator Post | |
| 2012800030 - Guide, Hub (Originally Shipped In Kit Number(s) 2012800030.) |
|
| 2019200030 - Installer, Rear Pinion Bearing | |
| 2029500030 - Socket, Hub Nut |
