Left Rear Cable

WARNING: This page is about a different car, the 2016 RAM 1500. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Parking Brake Cable

Courtesy of CHRYSLER GROUP, LLC

LOCKING PLIERS

1 - PARKING BRAKE CABLE

Raise and support the vehicle.
Lockout the parking brake cable (1).

Fig 2: Park Brake Cable End, Bracket & Adjuster Nut
Courtesy of CHRYSLER GROUP, LLC

Loosen the brake cable at the equalizer and adjuster nut (4).

Fig 3: Brake Cable End & Lever

Courtesy of CHRYSLER GROUP, LLC

1 - DISC BRAKE CALIPER

2 - DISC BRAKE ROTOR

3 - DUST SHIELD

4 - REAR PARKING BRAKE CABLE

5 - DISC BRAKE CALIPER MOUNTING BOLTS

Remove the left brake cable from the equalizer.
Remove the brake cable from the frame bracket.
Remove the brake cable end (3) from the brake lever (2).
