Left Bank

WARNING: This page is about a different car, the 2014 RAM 1500. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exhaust Manifold, Gaskets, Turbocharger, Cylinder Head & Fasteners
GC0146651Courtesy of CHRYSLER GROUP, LLC
  1. Clean the cylinder head and exhaust manifold sealing surfaces. Refer to ENGINE GASKET SURFACE PREPARATION  .
  2. Install new exhaust manifold gaskets (1 and 4), to the cylinder head (2) and the turbocharger (3).
  3. Install the exhaust manifold (6) and the retaining nuts (5 and 7) finger tight.
    Fig 2: Left Bank Exhaust Manifold Tightening Sequence
    GC0146652Courtesy of CHRYSLER GROUP, LLC
  4. Using the tightening sequence shown in illustration tighten nuts to:
    • Step 1: tighten nuts to 15 N.m (133 in. lbs.).
    • Step 2: Tighten nuts to 40 N.m (30 ft. lbs.).
    Fig 3: Exhaust Manifold Pipe To Turbocharger Heat Shield & Bolts
    GC0146648Courtesy of CHRYSLER GROUP, LLC
  5. Install the exhaust heat shield (1). Tighten bolt (2) to 15 N.m (133 in. lbs.).
    Fig 4: Left Exhaust Manifold Heat Shield & Bolts
    GC0146647Courtesy of CHRYSLER GROUP, LLC
  6. Install the left exhaust manifold heat shield (2). Tighten bolts (1) to 15 N.m (133 in. lbs.).
    Fig 5: Remove/Install Oil Cooler Assembly
    GC0158173Courtesy of CHRYSLER GROUP, LLC
  7. Install the oil cooler adapter. Refer to ADAPTER, OIL COOLER, INSTALLATION .
  8. Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
    Fig 6: A/C Compressor Bracket & Bolts
    GC0146757Courtesy of CHRYSLER GROUP, LLC
  9. Install the A/C compressor mounting bracket. Tighten bolts to 45 N.m (33 ft. lbs.).
  10. Position the A/C compressor to the A/C compressor bracket (7) and install the stud (3). Tighten the stud (3) to 11 N.m (97 in. lbs.).
  11. Install and hand tighten the nut (4) that secures the A/C compressor to the bracket.
  12. Tighten the nut (4) at the front of the A/C compressor to 30 N.m (22 ft. lbs.).
  13. Install the rear A/C compressor mounting bolt and tighten to bolt to 30 N.m (22 ft. lbs.).
  14. Install the serpentine belt. Refer to BELT, SERPENTINE, INSTALLATION .
  15. Install the transmission. Refer to INSTALLATION .
  16. Lower the vehicle.
  17. Fill the cooling system. Refer to STANDARD PROCEDURE .
  18. Connect the negative battery cable.
  19. Start the engine and check for leaks.
    Fig 7: Removing/Installing Engine Cover
    GC0158138Courtesy of CHRYSLER GROUP, LLC
  20. Install the engine cover (1).
