Retainer, Battery: Installation: Installation
WARNING: This page is about a different car, the 2013 RAM 3500 HD and 2013 RAM 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.
- Clean and inspect the battery hold down retainer (5) and bolt (6). Refer to CLEANING .CAUTION:
Be certain that the hold down bracket is properly positioned in the battery tray before tightening the hold down bolt or damage to the battery and tray may result.
- Install the battery hold down retainer. Tighten bolt to 5 N.m (44 in. lbs.).
- Connect both negative battery cables.
