Left

REMOVAL





1. Remove air cleaner assembly.
2. Disconnect negative cable from battery.
3. Remove bolts attaching the power distribution center (PDC) bracket (2) to left mount and battery tray (3).










4. Support transaxle (3) with a suitable jack.
5. Remove mount to transaxle bolts (1).
6. Remove left mount (2) bracket to body frame rail fasteners.
7. Remove mount (2).
