Engine Block Heater - Description






ENGINE BLOCK HEATER










The block heater (1) is mounted in a core hole (in place of a core hole plug) in the engine block with the heating element immersed in coolant.










The engine block heater is available as an optional accessory. The heater is powered by ordinary house current (110 Volt AC) through a power cord (3) and connector (2).
