Rear Bumper Fascia - Removal

REMOVAL










1. Open liftgate.
2. Remove the rubber body plugs or mastic tape patches, if equipped.
3. Remove nuts attaching fascia to lower floor closure.










4. Raise vehicle on hoist.
5. Disconnect license lamp.
6. Remove splash shield from fascia in the wheel opening area Splash Shield - Removal.
7. Remove screws attaching fascia to lower quarter panels.
8. Remove fascia from vehicle.
