LAMP, Dome: Removal: Unit
WARNING: This page is about a different car, the 2009 Dodge Caliber. However, it is still accessible from the selected car via links, so may be relevant.
- On lower line vehicles, there will be two overhead lamps located at (1 and 2). (1) is the Cargo Lamp, and (2) is the Dome Lamp.
- From the front of the dome lamp, insert a trim stick between the dome lamp unit bezel (3) and the headliner and gently pry down to release the clip (5) holding the unit to the roof panel , and the two clips (1) holding it to the headliner.
- Pull the dome lamp forward to release the two tabs (3) from the headliner.
- Disconnect the wire connector (2).
- Remove the dome lamp unit from vehicle.
