FASCIA, Front: Removal: Removal
WARNING: This page is about a different car, the 2009 Dodge Caliber. However, it is still accessible from the selected car via links, so may be relevant.
- Remove splash shield. Refer to Body/Exterior/SHIELD, Splash - Removal .
- Remove left and right side fastener (1) located in the wheel well.
- Remove three fasteners (2) located at the bottom of fascia.
- Remove middle fasteners (8) located on the top of the fascia.
- If equipped, disconnect fog lamps (1).
- Remove two fasteners located at the top of fascia (7).
- Carefully, remove fascia from vehicle.
