Measuring Crankshaft End Play

Fig 1: Checking Crankshaft End Play - Typical
GC0114556Courtesy of CHRYSLER LLC
  1. Mount a dial indicator to front of engine with the locating probe on nose of crankshaft .
  2. Move crankshaft all the way to the rear of its travel.
  3. Zero the dial indicator.
  4. Move crankshaft all the way to the front and read the dial indicator. See Engine - Specifications  for end play specification.
