Section 87 (G288 Manual Transmission - Overhaul)
>>
Special Tools
Special Tools
WARNING:
This page is about a different car, the 2006 Chrysler PT Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Puller Set 5048
Courtesy of DAIMLERCHRYSLER CORP.
Fig 2: Installer, 6448
Courtesy of DAIMLERCHRYSLER CORP.
Fig 3: Clutch Line Disconnect Tool 6638A
Courtesy of DAIMLERCHRYSLER CORP.
Fig 4: Remover, 6954
Courtesy of DAIMLERCHRYSLER CORP.
Fig 5: Installer, 8864
Courtesy of DAIMLERCHRYSLER CORP.
Fig 6: Installer, 8866
Courtesy of DAIMLERCHRYSLER CORP.
Fig 7: Remover/Installer, 8868
Courtesy of DAIMLERCHRYSLER CORP.
Fig 8: Fixture, 8869
Courtesy of DAIMLERCHRYSLER CORP.
Fig 9: Remover, 8870
Courtesy of DAIMLERCHRYSLER CORP.
Fig 10: Installer, 8871
Courtesy of DAIMLERCHRYSLER CORP.
Fig 11: Remover, 8911
Courtesy of DAIMLERCHRYSLER CORP.
Fig 12: Remover, 8912
Courtesy of DAIMLERCHRYSLER CORP.
Fig 13: Remover, 8913
Courtesy of DAIMLERCHRYSLER CORP.
Fig 14: Brace Tool, 8915
Courtesy of DAIMLERCHRYSLER CORP.
Fig 15: Installer, 8916
Courtesy of DAIMLERCHRYSLER CORP.
Fig 16: Support Base, 8917
Courtesy of DAIMLERCHRYSLER CORP.
Fig 17: Protect Sleeve, 8918
Courtesy of DAIMLERCHRYSLER CORP.
Fig 18: Protect Button, 8919
Courtesy of DAIMLERCHRYSLER CORP.
Fig 19: Installer, 8921
Courtesy of DAIMLERCHRYSLER CORP.
Fig 20: Protector, 8923
Courtesy of DAIMLERCHRYSLER CORP.
Fig 21: Installer, 8924
Courtesy of DAIMLERCHRYSLER CORP.
Fig 22: Fixture, 8925
Courtesy of DAIMLERCHRYSLER CORP.
Fig 23: Remover, 8926
Courtesy of DAIMLERCHRYSLER CORP.
Fig 24: Installer, 8953
Courtesy of DAIMLERCHRYSLER CORP.
Fig 25: Puller/Slide Hammer C-3752
Courtesy of DAIMLERCHRYSLER CORP.
Fig 26: Universal Driver Handle - C4171
Courtesy of DAIMLERCHRYSLER CORP.
Fig 27: Bearing Splitter P-334
Courtesy of DAIMLERCHRYSLER CORP.
