Front Suspension
WARNING: This page is about a different car, the 2006 Dodge Magnum, 2006 Dodge Charger, and 2006 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
The front suspension for both All-Wheel-Drive (AWD) and Rear-Wheel-Drive (RWD) vehicles is a long and short arm design.
Each side of the AWD front suspension includes the following components:
- Hub And Bearing
- Knuckle (4)
- Lower Control Arm (4)
- Shock Assembly (2)
- Stabilizer Bar and Link (2)
- Upper Control Arm (1)
Each side of the RWD front suspension includes the following components:
- Hub And Bearing
- Knuckle (3)
- Lower Control Arm (5)
- Shock Assembly (1)
- Stabilizer Bar (6) and Link (7)
- Tension Strut (4)
- Upper Control Arm (2)
