Rear Center - Wagon

WARNING: This page is about a different car, the 2006 Dodge Magnum, 2006 Dodge Charger, and 2006 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Seat Back Trim Cover
GC0016667Courtesy of DAIMLERCHRYSLER CORP.
  1. Position the rear center retractor into position in the seat back.
  2. Install the one bolt (2) holding the rear center seat belt retractor. Torque nut to 34 N.m (25 ft. lbs.).
  3. Install the left seat back trim cover (60% portion of the rear folding seats) (Refer to BODY/SEATS/SEAT - INSTALLATION) .
