INJECTOR(S), Fuel: Installation: 5.7L/6.1L
WARNING: This page is about a different car, the 2010 Dodge Charger and 2010 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
- Apply a small amount of engine oil to each fuel injector o-ring. This will help in fuel rail installation.
- Install injector(s) (4) and injector clip(s) (3) to fuel rail.
- Install fuel rail assembly. See Fuel System/Fuel Delivery/RAIL, Fuel - Installation .
- Start engine and check for leaks.
