Mark Centerline On Rear Glass
WARNING: This page is about a different car, the 2010 Dodge Charger and 2010 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
- Take a measurement across the upper edge (2) of the rear glass using the vertical edges of the body opening as the reference points.
- Divide the upper measurement in half and mark that dimension on the glass using a grease pencil or equivalent. This is the upper centerline of the glass.
- Take a measurement across the lower edge (1) of the glass using the vertical edges of the body opening as the reference points.
- Divide the lower measurement in half and mark that dimension on the glass using a grease pencil or equivalent. This is the lower centerline of the glass.
- Connect the top center mark and the lower center mark and mark a straight line (3) for the center of the glass.
