Section 305 (Starting System (Service Information)): Starter: Installation: 2.7L

WARNING: This page is about a different car, the 2010 Dodge Charger and 2010 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Removing/Installing Starter

Courtesy of CHRYSLER LLC

Position starter up and pass the transmission and exhaust.

Fig 2: Starter Position Past Intermediate Steering Shaft
Courtesy of CHRYSLER LLC
Move starter up and pass the intermediate shafts.

Fig 3: Starter Position
Courtesy of CHRYSLER LLC
Starter pass the intermediate shaft.

Fig 4: Starter Removal/Install
Courtesy of CHRYSLER LLC
Position starter up toward engine.

Fig 5: Dust Shield And Plastic Retainer
Courtesy of CHRYSLER LLC
Install plastic retainer into starter dust shield. The dust shield has TOP marked on it and the plastic retainer goes in the hole.

Fig 6: Plastic Retainer
Courtesy of CHRYSLER LLC
Plastic retainer installed.
Install dust shield to the engine block using the plastic retainer to hold dust shield in place.

Fig 7: Starter Mounting Bolts
Courtesy of CHRYSLER LLC
Install starter and starter bolts. Tighten bolts to 54.2 N.m (40 ft. lbs.).

Fig 8: Removing/Installing Starter Cable Electrical Connection
Courtesy of CHRYSLER LLC
Install electrical connection to starter.

Fig 9: Steering Shaft Removed
Courtesy of CHRYSLER LLC
Match flats inside intermediate shaft with that in intermediate shaft extension, then slide intermediate shaft onto extension.

Fig 10: Steering Shaft Connected
Courtesy of CHRYSLER LLC
Align the hole in the shafts.

Fig 11: Intermediate Steering Shaft Center Bolt
Courtesy of CHRYSLER LLC
Install pinch bolt fastening intermediate shaft to intermediate shaft extension.
Tighten pinch bolt to 43 N.m (32 ft. lbs.).
Install the underbody splash shield.
Lower vehicle.
Remove the steering wheel holder.
Connect negative battery cable.
