2.7L 2nd
WARNING: This page is about a different car, the 2010 Dodge Charger and 2010 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of CHRYSLER LLC
The ignition capacitor is located under the intake manifold on the drivers side of the engine.
- Disconnect and isolate negative battery cable at battery.
- Remove electrical connector (3).
- Remove mounting bolt (1) and ignition capacitor (2).
