MAP SENSOR 2.0, 2.4, 2.4L Turbo

WARNING: This page is about a different car, the 2007 Chrysler PT Cruiser. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Manifold Absolute Pressure Sensor

Courtesy of CHRYSLER LLC

The MAP sensor attaches to the intake manifold plenum (1).

Remove the air cleaner lid and makeup air hose.
Remove the negative battery cable.
Disconnect the electrical connector from the MAP sensor.
Remove sensor mounting screws.
Remove sensor.
