Clutch Interlock/UPSTOP Switch: Removal: RHD

WARNING: This page is about a different car, the 2006 Chrysler PT Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Lower Instrument Panel Bezel
G04241533Courtesy of DAIMLERCHRYSLER CORP.
  1. Remove lower instrument panel bezel (2). See Fig 1.
    Fig 2: Clutch Interlock/Upstop Switch
    GC0019780Courtesy of DAIMLERCHRYSLER CORP.
    1 - INTERLOCK/UPSTOP SWITCH
    2 - CLUTCH MASTER CYLINDER
    3 - CONNECTOR
  2. Disconnect the master cylinder push rod from the pedal pin. Inspect push rod retainer for damage. If it is damaged (broken/cracked), it must be replaced.
  3. Squeeze together the tangs on the switch cover plate and slide the plate off the switch housing.
  4. Disconnect the clutch interlock/upstop switch connector (3) from the instrument panel wiring harness. See Fig 2.
  5. Remove the switch from the vehicle (1).
