Switch-Seat Belt-Driver (D2278)

Harness-Family: Body

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6443-40

Part Description: 2P KAIZEN YESC 1.5MM Female SUB ASSEMBLY

Connector No: D2278

Option: BASE

Repair Kit Part Number: 68065023AA

Cavity Count: 2

Fig 1: Switch-Seat Belt-Driver Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt-Driver Component Location

Courtesy of CHRYSLER
