Switch-Parking Brake (D2269)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 520961-1

Part Description: INSL

Connector No: D2269

Option: Standard

Repair Kit Part Number: 05019927AA

Cavity Count: 1

Fig 1: Switch-Parking Brake Connector End View

GCWD1006399

Courtesy of CHRYSLER

Fig 2: Switch-Parking Brake Component Location

GCWD1022976

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	B25	GY	20	PARK BRAKE SWITCH SENSE	N/A
