Switch-Hood Ajar (D2245)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 04801212AA

Part Description: INS ASSY

Connector No: D2245

Option: Standard

Repair Kit Part Number: 05017129AA

Cavity Count: 2

Fig 1: Switch-Hood Ajar Connector End View

GCWD1025385

Courtesy of CHRYSLER

Fig 2: Switch-Hood Ajar Component Location

GCWD1022182

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	G70	VT	20	HOOD AJAR SWITCH SENSE	N/A
2	Z904	BK	20	GROUND	N/A
