Starter C2 (D6637B)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 520961-1

Part Description: INSL

Connector No: D6637B

Option: 2.7L/3.5L/5.7L AWD

Repair Kit Part Number: 05019927AA

Cavity Count: 1

Fig 1: Starter C2 Connector End View

GCWD1006399

Courtesy of CHRYSLER

Fig 2: Starter C2 Component Location

GCWD1023381

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
B1	T750	LG	16	STARTER RELAY OUTPUT	N/A
