S388 (S121)

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S121

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S388 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S388 Component Location

GCWD1017537

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	F921	PK	20	FUSED IGNITION RUN CONTROL OUTPUT	N/A
2	F921	PK	20	FUSED IGNITION RUN CONTROL OUTPUT	N/A
3	F921	PK	20	FUSED IGNITION RUN CONTROL OUTPUT	N/A
