S360 (S590)

Harness-Family: Door_Pass

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S590

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S360 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S360 Component Location

GCWD1024249

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z911	BK	14	GROUND	N/A
2	Z911	BK	20	GROUND	N/A
3	Z911	BK	20	GROUND	N/A
4	Z911	BK	22	GROUND	N/A
5	Z911	BK	20	GROUND	N/A
6	Z911	BK	14	GROUND	N/A
7	Z911	BK	14	GROUND	N/A
8	Z911	BK	22	GROUND	N/A
