S359 (S410)

Harness-Family: Door_Driver

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S410

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S359 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S359 Component Location

GCWD1019089

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A913	RD	20	FUSED B(+)	N/A
2	A913	RD	20	FUSED B(+)	N/A
3	A913	RD	20	FUSED B(+)	N/A
