S339 (S1431)

Harness-Family: Headliner

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1431

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S339 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S339 Component Location

GCWD1020438

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	M27	YL	18	READING LAMPS DRIVER	N/A
2	M27	YL	20	READING LAMPS DRIVER	N/A
3	M27	YL	20	READING LAMPS DRIVER	N/A
4	M27	YL	20	READING LAMPS DRIVER	N/A
5	M27	YL	20	READING LAMPS DRIVER	N/A
6	M27	YL	20	READING LAMPS DRIVER	N/A
