S338 (S1430)

Harness-Family: Headliner

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1430

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S338 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S338 Component Location

GCWD1020439

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	M24	YL	18	COURTESY LAMPS DRIVER	N/A
2	M24	YL	20	COURTESY LAMPS DRIVER	N/A
3	M24	YL	20	COURTESY LAMPS DRIVER	N/A
4	M24	YL	20	COURTESY LAMPS DRIVER	N/A
