S336 (S186)

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S186

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S336 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S336 Component Location

GCWD1019029

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D65	WT	22	CAN C (+)	N/A
2	D65	WT	22	CAN C (+)	N/A
3	D65	WT	22	CAN C (+)	N/A
4	D65	WT	22	CAN C (+)	N/A
