S321 (S125)

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S125

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S321 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S321 Component Location

GCWD1017542

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	F922	RD	12	FUSED IGNITION SWITCH OUTPUT	N/A
2	F922	RD	20	FUSED IGNITION SWITCH OUTPUT	N/A
3	F922	RD	20	FUSED IGNITION SWITCH OUTPUT	N/A
4	F922	RD	12	FUSED IGNITION SWITCH OUTPUT	N/A
